产品介绍：
产品说明
应用
PBDTS-TDZ is a wide bandgap polymer that can be used as a donor for the fabrication of organic solar cells. It has alkylthio side chains, which help in strong optical absorption and high crystallinity. PBDTS-TDZ forms a composite with ITIC, which has an efficiency of ~18% for organic tandem solar cells.
基本信息
| 线性分子式 | [C68H92N2S9]n |
| NACRES | NA.23 |
产品性质
| 描述 | Band gap: 2.09 eV |
| 形式 | powder |
| 分子量 | average Mn >30000 average Mw >60000 |
| 溶解性 | THF: soluble chlorobenzene: soluble chloroform: soluble dichlorobenzene: soluble soluble (1,2,4-trimethylbenzene) toluene: soluble xylene: soluble |
| λmax | 510 nm±10 nm (Solution) |
| 轨道能量 | HOMO -5.39 eV LUMO -2.8 eV |
| PDI | <2.5 |
安全信息
| 储存分类代码 | 13 - Non Combustible Solids |
| WGK | WGK 3 |
| 闪点(F) | Not applicable |
| 闪点(C) | Not applicable |
